- AC Voltage Rating: 600V AC
- DC Voltage Rating: 300V DC
- Diameter: 1 25/32 in
- Overall Diameter: 1 25/32 in
- Amps: 110A
Specifications
| Part Number | FLSR110 |
| Brand | Littelfuse |
| Class | RK5 |
| Series | FLSR-ID |
| Speed | Time-Delay |
| AC Voltage Rating | 600V AC |
| DC Voltage Rating | 300V DC |
| Length | 9 5/8 in |
| Diameter | 1 25/32 in |
| Overall Diameter | 1 25/32 in |
| Overall Depth | 1 25/32 in |
| Overall Length | 9 5/8 in |
| Overall Width | 1 25/32 in |
| Amps | 110A |
| Visual Indication | Indicating |
| Interrupt Rating | 20k A at 300V DC |
| Body Style | Blade |
| Equivalent Brand and Series | Littelfuse FLSR-ID |
| Equivalent Series | FLSR-ID |
| Fits Fuse Block Style | Rejection |
| Compatible Fuse Block Series | LFR60 |
| Item | UL Class Fuse |
| Standards | CSA, cUL, UL |
| Element | Dual |
| Current | 110 A |
| Interrupt Rating – DC | 20 kA |
The Littelfuse FLSR110 is a 110A, 600V AC/300V DC UL Class RK5 time-delay indicating fuse from the FLSR-ID Series. This fuse provides overcurrent protection with a 20kA interrupting rating at 300V DC and is compatible with the LFR60 series fuse blocks.
