The AG Series Surge Protection Devices are designed for outdoor installations on service entrance panels and utility meter cabinets. This series is also approved for applications such as irrigation equipment, pumps, lighting fixtures, traffic signaling devices, farm equipment, HVAC controls and motors. The 12 gauge leads are 18-Inch long and color coded for easy wiring. Parallel MOVs from each line to grounded neutral provide increased product capability. Molded polycarbonate housing is weatherproof and UV resistant. The AG2401C3 is designed for 120/240 Volt single phase applications and meets the ANSI/UL1449 3rd Edition requirements.
The devices feature a 4.4 millimeter height size, 50/60 Hertz frequency rating, and ANSI/UL 1449, CSA approval for light commercial, outdoor, 3-phase rooftop HVAC unit application. The green LED light indicates the product is energized and protecting your valuable electronic devices, providing three modes of protection. The Type 4X watertight, plastic enclosure is suitable for outdoor installations and the UV-resistant polycarbonate housing ensures durability. A 1⁄2″ threaded nipple for 7⁄8″ nominal conduit knockout is also provided, along with a 1-year product warranty and UL listing to ANSI/UL 1449 3rd edition.
In summary, the AG Series Surge Protection Devices offer robust, weatherproof, and UL-certified protection for a wide range of outdoor applications, from HVAC units to irrigation equipment, with features such as parallel MOVs, color-coded wiring, and a green LED indicator for added convenience and safety.
product information:
| Attribute | Value | ||||
|---|---|---|---|---|---|
| manufacturer | Intermatic | ||||
| part_number | AG2401C3 | ||||
| item_weight | 5.6 ounces | ||||
| product_dimensions | 7.4 x 5.2 x 3.5 inches | ||||
| item_model_number | AG2401C3 | ||||
| is_discontinued_by_manufacturer | No | ||||
| color | Black | ||||
| material | Plastic | ||||
| shape | Rectangle | ||||
| voltage | 240 Volts | ||||
| amperage_capacity | 15 Amps | ||||
| item_package_quantity | 1 | ||||
| plug_format | Type B | ||||
| special_features | Waterproof, Surge Protection | ||||
| usage | personal | ||||
| included_components | AG2401C3 | ||||
| batteries_included | No | ||||
| batteries_required | No | ||||
| warranty_description | Replace product | ||||
| customer_reviews |
|
||||
| best_sellers_rank | 61,569 in Electronics (See Top 100 in Electronics) 439 in Surge Protectors |
||||
| date_first_available | June 8, 2010 |
