The Sargent 80 Series rim exit device delivers ANSI/BHMA Grade 1 strength and durability for wood or metal doors. Ideal for commercial facilities requiring reliable emergency egress hardware, this maintenance-free device features modular construction with few moving parts, ensuring consistent performance throughout the building’s life.
This 32D finish model fits standard 1-3/4″ thick doors and is available with options for delayed egress, alarmed exit, and electric latch retraction. Compatible with E, F, J, and G rail configurations for door widths from 24″ to 48″. Contact our security experts at [email protected] or 1-877-207-6067 for proper sizing, installation guidance, and access to our full range of Sargent exit devices.
Specifications
- Brand: Sargent
- Model: 80 Series 1943-AD8510E
- Finish: 32D
- Configuration: Rim exit device
- Door Types: Wood or metal, 1-3/4″ (44mm) thick
- Minimum Stile Width: 1-3/4″ (44mm)
- E Rail: 24″ to 32″ (61cm to 81cm)
- F Rail: 33″ to 36″ (84cm to 91cm)
- J Rail: 37″ to 42″ (94cm to 107cm)
- G Rail: 43″ to 48″ (110cm to 122cm)
- Standard: ANSI/BHMA Grade 1
