The Sargent 8227 LE1E 32D is a heavy-duty mortise lock engineered for commercial and institutional doors requiring maximum security and durability. Exceeding ANSI/BHMA A156.13 Grade 2 standards, it delivers superior strength for offices, hospitals, schools, and behavioral health facilities where reliability and resistance to tampering are essential.
This mortise lock is UL-cUL listed for three-hour fire doors and compatible with multiple security key systems including Degree, Signature, KESO, and XC. Available in 58 functions with 6 lever designs and 14 finishes, it features thru-bolted trim and a strengthened cylinder retainer. As an authorized Sargent dealer, E.D. Locks provides expert configuration assistance and a 10-year warranty. Contact [email protected] or 1-877-207-6067 for keying options and installation support.
Specifications
- Brand: Sargent
- Model: 8227 LE1E 32D
- Certification: ANSI/BHMA Grade 2, UL-cUL Listed
- Fire Rating: Three-hour fire doors and windstorm applications
- Security Key Systems: Degree, Signature, KESO, XC
- Available Functions: 58
- Lever Designs: 6
- Rose/Escutcheon Designs: 2
- Architectural Finishes: 14
- Warranty: 10 years
- Features: Thru-bolted lever trim, strengthened cylinder retainer, behavioral health trim option
