SprintIR6S Ultra-Fast 20% CO2 Sensor
-44%

SprintIR6S Ultra-Fast 20% CO2 Sensor

in sensors
Sku: SPRINTIR-6S-20

$124.70 Save:$98.00(44%)

Category:
Description

The SprintIR®-6S-20 20% CO2 Sensor (formerly known as the GC-0029) is a high-speed CO2 sensor that can take up to 20 readings per second, making it ideal for applications that require individual measurements at high repetition rates or where the CO2 concentration is changing rapidly.

The sensor is fitted with a standard flow-through adaptor so the CO2 gas can be passed over the optical sensor at high speed.

The SprintIR®-6S 20% CO2 Sensor uses patented NDIR solid-state LED optical technology enabling the sensor to respond to rapidly changing CO2 without compromising parametric performance.

**Please Note: 6-8 week lead time**

Features

  • NDIR LED sensor measures up to 20% CO2
  • Fast response rate – 20 readings/second
  • Digital UART output
  • Easy integration in food packaging or scientific applications

Models

  • SprintIR®-6S-20 Sensor – for integration into high-volume OEM products.
  • CM-20400 – 20% CO2 sensor w/ Board
  • CM-20401– 20% CO2 sensor w/ Development Kit to build on to your own application, further test and configure

Specifications

  • CO2 Sensing Method: Non-dispersive infrared (NDIR) absorption
  • Sample Method: Solid-state LED NDIR Diffusion
  • Measurement Range: 0-20%
  • Accuracy: ±70 ppm +/- 5% of reading @ STP
  • Time to 1st Reading: <0.5 Seconds
  • Accuracy @ 100% Range: ±300 ppm +/-5% of reading @ STP
  • Operating Conditions – Temperature: 0°C to 50°C
  • Storage Conditions – Temperature: -40°C to +70°C
  • Operating Conditions – Humidity: 0-95% RH, non-condensing
  • Resolution: 10 ppm
  • Non Linearity: <1% of FS
  • Pressure Dependence: 0.13% of reading per mbar @STP
  • Warm-up Time: <30s.
  • Response Time: Flow Rate Dependent
  • Operating Conditions: 0°C to 50°C, 0 to 95% RH, non-condensing
  • Sensor Lifespan: > 15 years

Electrical / Mechanical

  • Power Input: 3.25 to 5.5V. (3.3V recommended)
  • Peak Current: 33mA @ 2 readings/sec.
  • Average Current: <12mA
  • Power Consumption: 3.5mW @ 2 readings/sec.
  • Interface: UART (Serial)
  • Dimensions: 25mm x 40mm x 31mm on PCB (LxWxH)
  • Weight: 16g sensor, 5.8g board

Warranty

  • 90 days – See CO2Meter Terms and Conditions
